Products & Services
Feeder Cable Clamp, 12 holes, 3×13-20mm+9×4.5-5.5mm,With Pat.Pending and Maxdao logo

Feeder Cable Clamp, 12 holes, 3×13-20mm+9×4.5-5.5mm,With Pat.Pending and Maxdao logo

Item Number 6008741

Easy and quick installation. Robust design & material for outdoor use. Operation Temperature -40~85 ℃.Patented product.

Classification
Item Number	6008741
Part number	–
Detail Description	Feeder cable clamp, for 3×13-20mm OD cable and 9×4.5-5.5mm OD cable

General Specifications
Metal Material	Stainless Steel 304
Metal Color	Natural
Block Material	POM
Block Color	Black
Rubber Material	EPDM
Rubber Color	Black
Mounting	M8 Hardware
Cables Per Hanger	12
Dimensions
Height	36.0 mm \| 1.42 in
Width	63.9 mm \| 2.52 in
Length	190.0 mm \| 7.48 in
Threaded Rod Length	120.0 mm \| 4.72 in
Compatible Cable 1 OD, maximum	20.0 mm \| 0.78 in
Compatible Cable 1 OD, minimum	13.0 mm \| 0.51 in
Compatible Cable 2 OD, maximum	5.5 mm \| 0.217 in
Compatible Cable 2 OD, minimum	4.5 mm \| 0.177 in
Environmental Specifications
Operating Temperature	-40°C to +85°C(-40°F to+185°F)
Environmental Strength Capability	Double Cable Weight
UV Resistance	≥720 Hours, base on ISO4892.3-1994
Packaging and Weights
Height, Packed	320 mm \| 12.60 in
Width, Packed	220 mm \| 8.66 in
UOM	1 Pcs
Packaging	Bag
Weight, Gross	0.258 kg \| 0.569 lbs
Certifications and Compliance
ISO 9001:2015	Designed, manufactured and/or distributed under this quality management system
RoHS	Compliant
